| Models | LEDDLE10WCCT | LEDDLE10WXX |
|---|---|---|
| Wattage | 10W | 10W |
| Lumens | 900 lm | 900 lm |
| Colour Temperatures | 3000K;4000K;5700K | DIP Switch CCT (3 Step): 3000K/4000K/5700K |
| Input Voltage | 220-240V~50/60Hz | |
| Power Factor | 0.95, Flicker Free | |
| IP Rating | IP44 For Front-Face Only | |
| Dimming (Options) | DALI - Dali Dimming;DSI - Digital Serial Interface; AD - Analogue Dimming;DIM - Leading/Trailing/Universal | |
| Beam Angle | 100° | |
| CRI | ≥80 Ra | |
| Body Material | Plastic | |
| Diffuser | Opal PC -Polycarbonate | |
Switch Cap and Input Cover | Transparent Plastic | |
| Product Colour | White | |
| Min/Max Operating Temp | -20℃ /+40℃ | |
| Life Time | 50,000 hrs | |
| Warranty | 3 years | |
| Certificates | SAA,C-Tick, ROHS,LM79,ISTMT,TM21 | |
| Remark | * "XX" in all models stands for color temperature,with 3K,4K,5K,6K,3K=3000K,4K=4000K,5K=5700K. * With SAA approved 1.5m Flex and Plug. | |
